PKNERGY 3U 48V 100Ah 5Kwh Rack Mounted Lifepo4 Battery with LCD Screen

Short Description:

PKNERGY Best Batteries For Solar Off Grid – Rack Mounted Battery
Battery Type: 3U 5Kwh Rack Mounted Lifepo4 Battery
Brand: PKNERGY
Rated voltage: 48V
Capacity :100Ah
Size ( mm) :480*482*133
Weight :44.2kg
Application :Solar off grid backup system, Solar Hybrid inverter UPS, Telecom UPS
Package :Polywood box


Product Detail

Product Tags



PKNERGY New Design 51.2V 100Ah 5Kwh Rack Mounted Lifepo4 Battery  (1)

Introduction of the Batteries For Solar Off Grid

When it comes to solar off-grid systems, choosing the right battery can make all the difference. The PKNERGY 3U 51.2V 100AH Rack Mounted Lifepo4 Battery is one of the best batteries for solar off-grid systems on the market. It adopts highly reliable Lithium battery cells, offering a long cycle life and consistent performance.

Features of the PKNERGY Rack Mounted Lifepo4 Battery

PKNERGY 3U 51.2V 100AH Rack Mounted Lifepo4 Battery packs use advanced Battery Management System (BMS) technology to enhance system performance, prolong battery life, and warrant safety. They come in various sizes and are easy to install with customization services available for panel options and support for parallel expansion. The Rack-Mounted Batteries (Server Rack Battery) are a great way to store energy and maintain electricity in the building.

Parameter of the PKNERGY Rack Mounted Lifepo4 Battery

No.

Item

General Parameter

Remark

1

Combination method

15S1P

48V 100Ah



2



Rated Capacity

Typical

100Ah

Standard discharge after Standard



charge (package)

Minimum

98Ah

3

Voltage Range 40.5~54.75V

4

Voltage at end of Discharge

40.5V

Discharge Cut- off Voltage

5

Charging Voltage

54.75V










6









Internal Impedance









≤20m Ω

Internal resistance measured at AC 1KHZ after 50% charge

The measure must uses the new batteries that within one week after

shipment and cycles less than 5 time

7

Standard charge Constant Current 0.2C Constant

Charge time(Approx):6.5h

8

Standard discharge Constant current: 0.2C end voltage


9

Maximum Continuous Charge



Current



100A



T≥ 10ºC



10

Maximum Continuous



Discharge Current



100A



T≥ 10ºC



11



Operation Temperature Range

Charge : 0~50℃

60± 25%R .H. Bare Cell

Discharge : -20~55℃




12





Storage Temperature Range

Less than 12 months :-10~35℃



60± 25%R .H. at the shipment state

less than 3 months: -10~45℃
Less than 7 day : -20~55℃

13

Dimensions

L480*W482*H133mm

14

Weight(Approx)

44.2kg

Applications of the PKNERGY Rack Mounted Lifepo4 Battery

PKNERGY 3U 51.2V 100AH Rack Mounted Lifepo4 Battery is an excellent energy storage solution for solar-wind power systems, city grids (on/off), community and family back-up systems, and UPS. Additionally, the battery is suitable for telecom bases, CATV systems, computer server centers, medical instruments, and military equipment.

Other Applications of the Rack Mounted Battery

PKNERGY 3U 51.2V 100AH Rack Mounted Lifepo4 Battery can also be used in other applications such as security and electronics, mobile POS, mining light, torch, LED light, emergency light, RV motorhomes, golf carts battery, boats marine yachts, electric skateboards, and engine starting battery.

Rack mounted battery(2)

Lifespan and Design of the Rack Mounted Battery

The PKNERGY 51.2V 100AH Rack Mounted Lifepo4 Battery offers a lifespan of 6000 cycles and a 20-year design life. The Lifepo4 battery life is ten times longer than ordinary batteries, making it a truly maintenance-free solution.

Customized solutions for off-grid solar Batteries

Investing in the PKNERGY 51.2V 100AH Rack Mounted Lifepo4 Battery is an excellent decision for businesses looking for reliability, durability, and energy cost savings. The battery’s long lifespan and advanced Battery Management System (BMS) technology make it an ideal solution for any solar off-grid system application.Custom solutions are available for the PKNERGY 51.2V 100AH Rack Mounted Lifepo4 Battery, tailor-made to meet individual needs. Please contact the manufacturer for more information.

PKNERGY New Design 51.2V 100Ah 5Kwh Rack Mounted Lifepo4 Battery with LCD Screen PKNERGY New Design 51.2V 100Ah 5Kwh Rack Mounted Lifepo4 Battery with LCD Screen
