PKNERGY New Design 4U 48V 100Ah 5Kwh Rack Mounted Lifepo4 Battery

Short Description:


Battery Type: PKNERGY LiFePO4 Server Rack Battery
Brand: PKNERGY
Rated voltage: 48V
Capacity :100Ah
Size ( mm) :460*482*178
Weight :42kg
Application :Solar off grid backup system, Solar Hybrid inverter UPS, Telecom UPS
Package :Polywood box


Product Detail

Product Tags



PKNERGY New Design 51.2V 100Ah 5Kwh Rack Mounted Lifepo4 Battery  (1)

Introduction of the Rack Mounted LiFePO4 Battery

The LiFePO4 Server Rack Battery has revolutionized how businesses store and use energy. PKNERGY 4U 48V 100AH Rack Mounted LiFePO4 Battery is a reliable and efficient energy storage solution, designed to provide a consistent source of power for a wide range of applications.

Features of the Rack Mounted LiFePO4 Battery

PKNERGY 4U 48V 100AH Rack Mounted LiFePO4 Battery uses highly reliable lithium battery cells, ensuring a long cycle life and consistent performance. Its advanced Battery Management System (BMS) enhances system performance, prolongs battery life, and guarantees safety. The battery packs come in various sizes and are easy to install, with customization services available for panel options. Additionally, they can be used in parallel expansion for large-capacity applications.

Parameter of Rack Mounted LiFePO4 Battery

No.

Item

General Parameter

Remark

1

Combination method

15S1P

48V 100Ah



2



Rated Capacity

Typical

100Ah

Standard discharge after Standard



charge (package)

Minimum

98Ah

3

Voltage Range 40.5~54.75V

4

Voltage at end of Discharge

40.5V

Discharge Cut- off Voltage

5

Charging Voltage

54.75V










6









Internal Impedance









≤20m Ω

Internal resistance measured at AC 1KHZ after 50% charge

The measure must uses the new batteries that within one week after

shipment and cycles less than 5 time

7

Standard charge Constant Current 0.2C Constant

Charge time(Approx):6.5h

8

Standard discharge Constant current: 0.2C end voltage


9

Maximum Continuous Charge



Current



100A



T≥ 10ºC



10

Maximum Continuous



Discharge Current



100A



T≥ 10ºC



11



Operation Temperature Range

Charge : 0~50℃

60± 25%R .H. Bare Cell

Discharge : -20~55℃




12





Storage Temperature Range

Less than 12 months :-10~35℃



60± 25%R .H. at the shipment state

less than 3 months: -10~45℃
Less than 7 day : -20~55℃

13

Dimensions

L460*W482*H178mm

14

Weight(Approx)

42kg

Applications of LiFePO4 Server Rack Battery

LiFePO4 Server Rack Battery is suitable for a wide range of applications, including solar-wind power systems, city grids (on/off), community and family back-up systems, and UPS. Moreover, they are ideal for telecom bases, CATV systems, computer server centers, medical instruments, and military equipment.

Other Applications

PKNERGY 51.2V 100AH Rack Mounted LiFePO4 Battery can also be used in other applications such as security and electronics, mobile POS, mining light, torch, LED light, emergency light, RV motorhomes, golf carts battery, boat marine yachts, electric skateboards, and engine starting battery.

Rack mounted battery(2)

Lifespan and Design of 48V LiFePO4 Battery

The PKNERGY 51.2V 100AH Rack Mounted LiFePO4 Battery offers a lifespan of 6000 cycles and a 20-year design life. The LiFePO4 battery life is ten times longer than ordinary batteries, making it a truly maintenance-free solution.

Rack-Mounted Batteries (Server Rack Battery)

Electricity is a crucial aspect of daily energy consumption in any building. A rack-mounted battery such as the PKNERGY 51.2V 100AH Rack Mounted LiFePO4 Battery is an excellent way to maintain a steady electricity supply. Custom solutions are also available, tailored to individual needs.

The Best Solution for Rack Batteries

Investing in a LiFePO4 Server Rack Battery such as the PKNERGY 51.2V 100AH Rack Mounted LiFePO4 Battery is a smart decision for businesses looking for reliability, durability, and energy cost savings. The battery’s long life-span, safety features, and parallel expansion capability make it an ideal solution for businesses of all sizes.

PKNERGY New Design 51.2V 100Ah 5Kwh Rack Mounted Lifepo4 Battery PKNERGY New Design 51.2V 100Ah 5Kwh Rack Mounted Lifepo4 Battery
