PKNERGY 18650 Lithium Ion Battery Pack – 3.7V 4400mAh Customized

Short Description:

This lithium-ion pack is made of 2 balanced 2200mAh cells for a total of 4400mA capacity! The cells are connected in parallel and spot-welded to a protection circuit that provides over-voltage, under-voltage, and over-current protection.


Product Detail

Product Tags

Description

This lithium-ion pack is made of 2 balanced 2200mAh cells for a total of 4400mA capacity! The cells are connected in parallel and spot-welded to a protection circuit that provides over-voltage, under-voltage, and over-current protection.

Each cell can provide 1A of current for about 4 hours so all together the peak current you can draw is a little over 1.5 Amps. Note that these batteries are not designed to sustain such high loads, we suggest keeping any constant current draw under 1A.

The packs come with color-coded wires, and now they come with a JST 2-pin cable attached for use with our chargers! Because they have a high quality JST-or-compatible connector, the cable won’t snag or get stuck in a matching JST jack, they click in and out smoothly. The cables are rated for 2A so if you use them keep that in mind.

The included protection circuitry keeps the battery voltage from going too high (over-charging) or low (over-use) which means that the battery will cut out when completely dead at 2.5V. However, even with this protection, it is very important that you only use a LiIon/LiPoly constant-voltage/constant-current charger to recharge them and at a rate of 0.5C (2.2A) or less.

Like most lithium-ion packs, the batteries we sell do not have thermistors built-in. This is why we suggest charging at 0.25C or even less – 1A max in this case. Of course, you can charge at a lower rate – it’ll just take a little longer to fill up.

Type
PKNERGY 18650 Lithium Ion Battery Pack – 3.7V 4400mAh Customized
Brand
PKNERGY or OEM
Model
ICR18650 4400mAh 3.7V
Cycle life
500-1000 times
Certification
CE/RoHS/UN38.3/MSDS
Package
blister card, industrial package or customized…
PCB/PCM
with or without,both ok for us
Payment Term
100%TT in advance
Price Term
FOB (Shenzhen/Guangzhou/HongKong/Shanghai),Ex-works.CIF,C&F…

Packing:
Shrink/Blister card/colour box/clamshell/Customized Package
1. All shipping goods are 100% inspected and packed very well.

Our Service:

1.OEM Manufacturing welcome: Product, Package…
2.Sample order
3.We will reply you for your inquiry in 24 hours.
4.After sending, we will track the products for you once every two days, until you get the products. When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solve way for you.

Additional safety notes:

Do not use a NiMH/NiCad/lead-acid charger! Also, do not abuse these batteries, do not short, bend, crush, or puncture. Never charge or use unattended. Always inspect batteries and surrounding circuitry constantly for any damage, loose wiring, or the possibility of short circuits. Polarity matches all Adafruit LiPoly/LiIon chargers and boards, other brands may have reverse polarity and can destroy your battery. As with all Lithium-ion polymer batteries and with any power source – they should be used by experts who are comfortable working with power supplies.
