PKNERGY Powerwall 51.2V 300Ah 15Kwh LiFePO4 Battery with Roller for Home Energy Storage

Short Description:

  1. Product name: 51.2V 300Ah 15kwh Powerwall LiFePO4 Battery
  2. Application: Home
  3. Battery Type: LiFePO4
  4. Voltage:51.2V
  5. Capacity:300Ah
  6. Controller Type: MPPT
  7. Work Time (h): 24 hours
  8. Certificate: CE, UN38.3, MSDS,IEC/ISO9001/ISO1400
  9. Dimension: 680*480*180mm
  10. Cycle life: Over 6000 times at 80%DOD
  11. Cell type: 3.2v 100ah Lifepo4 Prismastic battery Cell


Product Detail

Product Tags

PKNERGY Powerwall 51.2V 300Ah 15Kwh LiFePO4 Battery with Roller for Home Energy Storage

51.2v 300Ah 15Kwh Wall-Mount LiFePO4 Battery with Roller is pack designed as an Energy storage system ess battery module. It can be used in series or in parallel. It is compatible with all industry-leading standard solar charge controllers, inverters.

Superior chemical and thermal stability, Lithium Iron Phosphate battery pack is the safest in the lithium-ion family. It includes Canbus, RS485 communication, Modules can be connected in parallel, and paralleled modules that communicate through RS485. Battery modules communicate with the inverter via the CAN interface. Compatible with CANBUS protocol, compatible with Growatt, Goodwe, Deye inverter.Supports parallel, Best for energy storage, and more extended cycle life Module Applications. This 15kwh energy storage system battery is easy to install and keep in parallel households, small industrial businesses, tiny houses, and homes.

Features

- 51.2v LFP-based ESS, long life expectancy of 15+ years.

- Battery bank Expandable in parallel as power needs to increase.

- Operates at 90% efficiency for more than 7000 times cycles.

- Offer up to 100% depth of discharge.

- integrated battery management system ( BMS ).

- Flexible control that covers all commercial fields.

- Quick and Easy Installation, Maintenance-free.

Battery Pack specifications

No

Item

General Parameter

Remark

1

Combination method

16S6P



2

Rated Capacity

Typical

300Ah Standard discharge after Standard chargepackage)

Minimum

298Ah

3

Factory Voltage

51.2V-53V

Mean Operation Voltage

4

Voltage at end ofDischarge

<=43.2V

Discharge Cut-off Voltage

5

Charging Voltage

57V



6

Internal Impedance

≤100mΩ

Under 20±5℃ Environment Temperature , the Usage Frequency of Fully Charge( 1KHz) , Use AC Internal Impedance test machine to test

7

Max Charging Current(Icm)

100A

Ampere-meter ,Maximum allowable charging current of the battery pack

8

 Limited  Charging Voltage(Ucl)

57.6V

Volta-meter (Serial*3.6V) ,Battery pack safe charging voltage

9

 Max Discharging current

200A

Maximum  discharge current allowed by the battery pack

10

Discharge Cut-off voltage(Udo)

43.2V

Voltage of the battery  when the discharge is stopped

11

Operation Temperature Range

Charge:0~55℃



Discharge: -20~60℃

12

Storage Temperature Range

-20℃~25℃

Recommend25±3℃);≤90%RH storage moisture range.

13

Single module Size/weight

622*185*760mm/125Kg (Wheel not included)

1PCS125kg
Main control box size/weight

/

/

powerwall battery supplierSolar Battery Energy System-Pknergy (2)

PKNERGY Battery Match Inverters Brands
PKNERGY Solar LiFePO4  Battery Certifications
Battery Cell Quality (2)
PKNERGY Battery Cell Quality
PKNERGY Factory Show
PKNERGY Solar Battery Safe Package
PKNERGY Solar Battery Projects
